16 QMA-50-3-1/133 NE

Produktnummer: 23017686
Huber Suhner
Lagerbeholdning:

Cable Group3 U41
Cable6 RADOX_RF_142
Cable4 RADOX_RF_400
Cable Entry Centre Contact soldered
Cable Entry Outer Contact crimped
Class 1037
Body Material Brass
Body Plating SUCOPLATE (R) Plating
Cable Group U9
Cable Group2 U11
Cable1 RG_400_/U
Cable2 RG_223_/U
Cable3 ENVIROFLEX_400
Cable5 ENVIROFLEX_142
Centre Contact Material Brass
Centre Contact Plating SUCOPRO Plating
Connector Description Right angle cable plug
CONNECTOR SERIES QMA
Crimp Ferrule Material Copper
Crimp Ferrule Plating SUCOPLATE (R) Plating
Dielectric Size 3 mm
Gender plug
Highlight1 QuickLock Interface
ID 16_QMA-50-3-1/133_N
Impedance 50
Insulator Material PFA / PTFE
Interface Frequency max. 18 GHz
Interface Standards QMA QLF compliant
Junction cable
2011/65/EC (RoHS) compliant
Mounting none
Number of Matings 100
Operating Temperature max. 85 °C
Operating Temperature min. -40 °C
Outer Contact Material Bronze
Outer Contact Plating SUCOPLATE (R) Plating
Packaging Single
PATTERN CLASSES 16
Weight 0.0081 kg
CONNECTOR SHAPE right-angle
Type Number 16_QMA-50-3-1/133_NE
OBJECT_ID 7008464
