SR_141_TP_M17_2M
MOQ = 150 MTR
| H+S | |
|---|---|
| Insulation resistance | 100000000 MΩ*m |
| Fire characteristics | contains halogene |
| Velocity of signal propagation | 69.5 % |
| Weight | approx. 52.1 g/m |
| Signal delay | 4.8 ns/m |
| Product code | SR_141_TP_M17 |
| Operating Voltage (at sea level) | ≤ 1.9 kVrms |
| Available as assembly only | No |
| Cable group | Y5 |
| Capacitance | 98.1 pF/m |
| Test voltage (50 Hz/1 min) | ≤ 5 kVrms |
| Installation temperature | -20 °C ... 60 °C |
| Directive | RoHS 2011/65/EU and (EU) 2015/863 |
| Operation temperature | -40 °C ... 125 °C |
| Rating | Compliant without exemption , Compliant |
| Screening effectiveness | 120 dB at frequency 0.1 GHz ... 18GHz |
| Static bending radius | 635 |
| Cable family | Semi-rigid: Semi-rigid, formable microwave cables |
| Operating frequency | 33 |
| Impedance | 50 Ω +/-1Ω |
| Regulation | REACH 1907/2006 Article 33 SVHC |
