K7023231
H+S | |
---|---|
Radome material | High impact plastic |
Ingress protection (IP Rating) | Mated / IP56 |
Dimensions | 70 mm x 110 mm (Height x Diameter) |
Environment (application) | Outdoor |
Back plate/base plate material | Aluminum |
Remarks | For further information please refer to data sheet. , Indicated VSWR values are valid for a metallic ground plane of 1M x 1M or larger. , Packaging size (outside): 117 x 117 x 114 mmRadiator and base: Aluminum.All metal parts of this antenna are DC grounded.Robust and car-wash proof vehicular antenna. |
Transport temperature | -40 °C ... 85 °C |
Radome colour | Black |
Bands | 440 MHz ... 450 MHz, VSWR 1.7450 MHz ... 465 MHz, VSWR 1.5465 MHz ... 470 MHz, VSWR 1.7 |
Flammability rating | ECE-R118 |
Antenna family | SENCITY® Road PUCK |
Storage temperature | -40 °C ... 85 °C |
Operation temperature | -40 °C ... 85 °C |
Back plate/base plate colour | Grey |
Product code | K7023231 |
Weight | 0.4 kg |
