82_MMCX-50-0-8/111_OM
Coaxial connector
|MMCX, 50 Ohm, Straight PCB female
| Height above PCB HA | 5.3mm |
| Weight | 0.0003kg |
| Engangement Force max. | 15N |
| Height of Stand Off HS | 0mm |
| Disengagement Force max. | 15N |
| Disengagement Force min. | 6N |
| Board Mounting Type | surface mount |
| External Remarks | PCB connector without stand-offs |
| Highlight2 | PCB connector without stand-offs |
| 2002/96/EC (WEEE) | no special marking needed |
| Class | 1183 |
| 2006/1907/EC (REACH) | compliant |
| Body Material | Brass |
| Body Plating | Gold Plating (without Nickel underplating) |
| Centre Contact Material | Copper Beryllium Alloy |
| Centre Contact Plating | Gold Plating (Nickel underplated) |
| Connector Description | Straight PCB jack |
| CONNECTOR SERIES | MMCX |
| Gender | jack |
| Highlight1 | Surface mount technology |
| ID | 82_MMCX-50-0-8/111_O |
| Impedance | 50 |
| Insulator Material | PFA / PTFE |
| Interface Frequency max. | 6GHz |
| Interface Standards | SUHNER-MMCX |
| Junction | none |
| 2011/65/EC (RoHS) | compliant |
| Mounting | pcb |
| Number of Matings | 500 |
| Operating Temperature max. | 155°C |
| Operating Temperature min. | -55°C |
| Outer Contact Material | Brass |
| Outer Contact Plating | Gold Plating (without Nickel underplating) |
| Packaging | Tape and Reel |
| PATTERN CLASSES | 82 |
| CONNECTOR SHAPE | straight |
| Type Number | 82_MMCX-50-0-8/111_OM |
| OBJECT_ID | 2624794 |
