727313
| H+S | |
|---|---|
| Radome material | Fiberglass |
| Ingress protection (IP Rating) | Mated / IP66 |
| Dimensions | 355 mm x 145 mm x 80 mm (Height x Width x Depth) |
| Environment (application) | Outdoor |
| Back plate/base plate material | Aluminium |
| Remarks | For further information please refer to data sheet. , Flange: Aluminum.Radiator: Copper.All screws and nuts: Stainless steel.Sealing: Neoprene and EPDM.Packaging size (outside): 151 x 90 x 415 mm |
| Radome colour | Grey |
| Antenna configuration | SiSo |
| Bands | 4M band: 87.5 MHz ... 108 MHz |
| Antenna family | SENCITY® Rail |
| Storage temperature | -40 °C ... 85 °C |
| Back plate/base plate colour | Grey |
| Product code | 727313 |
| Weight | 0.9 kg |
| Flammability rating | EN 45545-2 |
| Operation temperature | -40 °C ... 85 °C |
