| Frequency min. 2 |
3 GHz |
| Outer Contact |
Brass |
| to Ambient Temperature |
85 °C |
| Average Power |
1 W |
| Centre Contact Plating |
SUCOPRO Plating |
| VSWR2 |
1.15 |
| Power Linearly Derated to |
N W |
| Outer Contact Plating |
SUCOPRO Plating |
| Frequency min. Frame |
N GHz |
| VSWR Frame |
1.15 |
| Water and Dust Resistance |
IP68 (1 m, 24 h) |
| Type Number1 |
65_N-50-0-53/113_NE |
| Packaging1 |
Single |
| Frequency max. Frame |
6 GHz |
| Weight |
0.0238 kg |
| Nominal Impedance 1 |
50 |
| Interface Standard1 |
IEC 60169-16_MIL-STD-348A/304_CECC 22210 |
| Body Heat Sink |
Brass |
| Return Loss2 |
23 dB |
| Centre Contact |
Brass |
| Body Heat Sink Plating |
SUCOPRO Plating |
| Matings |
100 |
| at Ambient Temperature |
115 °C |
| Return Loss Frame |
23 dB |
| Termination Description |
Standard Termination, Low Power |
| Coupling Nut Platin |
SUCOPLATE (R) Plating |
| Connector Gender 1 |
plug (male) |
| Insulator |
PTFE (Polytetrafluoroethylene) |
| Coupling Nut |
Brass |
| 2002/96/EC (WEEE) |
special marking needed |
| Class |
1195 |
| Connector Series 1 |
N |
| Frequency max. 2 |
6 GHz |
| Frequency max. 1 |
3 GHz |
| Frequency min. 1 |
N GHz |
| ID |
65_N-50-0-53/113_N |
| 2011/65/EC (RoHS) |
compliant |
| Operating Temperature max. |
115 °C |
| Operating Temperature min. |
-40 °C |
| Return Loss1 |
26.44 dB |
| VSWR1 |
1.1 |
| OBJECT_ID |
7138815 |
