48-12E9/BWSN(ZNG)H-G96#D

Produktnummer: 85020262
Huber Suhner
Lagerbeholdning:

Water penetr Standard IEC 60794-1-2 F5B
Impact Standard IEC 60794-1-2 E4
Stripping Ripcord for easy jacked removal
Tension Test Standard IEC 60794-1-2 E1
Strain Reliefed Armouring Rodent-protected, glass-armoured
Wavelength for singlemode at 1550nm, for multimode at 1300nm
Fire Standard Single IEC 60332-1-2
Layer Type 2 Ripcords
Temperature Standard IEC 60794-1-22 F1
Crush Test Standard IEC 60794-1-2 E3
Fire Standard Bundle IEC 60332-3-25
Fire Standard Circuit IEC 60331-25
Strength Member Type Strength member and 1 swellable roving
Other Properties Longitudinal and transversal watertight cable
Trademark LSFH
Class 1032
Cable Type Metal free indoor and outdoor cable
Cable Description Multi-fiber Loose Tube Cable
Outer Jacket Type Outer jacket / PE flame retardant (LSFH)
Outer Jacket Ø 9.6mm
Reinforcement Type Reinforcement / glass-roving
Number of max. Fibres 48
Tube Type Multi-fiber loose tube up to 12 fibers
Fire behavior Low smoke, halogen free and self-extinguishing
ID 48-.../BWSN(ZNG)H-...96
OBJECT_ID 7719033
