3402.41.0038
| Gender Protected Side | jack (female) |
| Thread | M8 |
| Side of Bulkhead | protected side |
| CW Power Frame | 150W |
| Temperature Shock | MIL-STD-202, Method 107, Cond. B |
| Current Handling 8/20 | 30 single / 20 multiple |
| Vibration | MIL-STD-202, Method 204, Cond. D |
| Weight | 434g |
| IP Rating | IP65 |
| Connector Port 1 | 7/16 |
| Insertion Loss Frame | 0.2dB |
| Frequency min. Frame | 0MHz |
| Residual Pulse Energy | 350µJ |
| Description Port2 | protected |
| Frequency max. Frame | 2500MHz |
| Description Port1 | unprotected |
| Center Contact Plating (Port 2) | Silver Plating |
| Right Angle | false |
| PIM 3rd Frame | not specified |
| Center Contact (Port 1) | Copper Beryllium Alloy |
| Gender Unprotected Side | jack (female) |
| Gas Tube | Yes DC, GDT not included |
| Center Contact (Port 2) | Copper Beryllium Alloy |
| Return Loss Frame | 20dB |
| Connector Port 2 | 7/16 |
| Moisture Resistance | MIL-STD-202, Method 106 |
| Mounting Hole | 74 |
| Highlight5 | Data refer to GDT 9071.99.0547, 230 V |
| Highlight4 | Delivered without gas discharge tube |
| Center Contact Plating (Port 1) | Silver Plating |
| Highlight3 | The protector can also be installed reversely |
| Highlight2 | DC continuity for remote powering |
| 2002/96/EC | special marking needed |
| Class | 1217 |
| 2006/1907/EC (REACH) | compliant |
| Housing | Brass |
| RF Protector Description | GDT technology up to 2.5 GHz |
| Housing Plating | SUCOPLATE (R) Plating |
| Highlight1 | Broad-band design |
| ID | 3402.41.0038 |
| Impedance | 50 |
| 2011/65/EC | compliant |
| Number of Matings | 500 |
| Operating Temperature max. | 85°C |
| Operating Temperature min. | -40°C |
| OBJECT_ID | 7140220 |
