11 SMA-50-2-15/111 NH
Coaxial connector
|SMA, 50 Ohm, Straight cable female
| Cable Group3 | Y16 |
| Cable Entry Centre Contact | soldered |
| Cable Entry Outer Contact | soldered |
| Class | 1037 |
| Body Material | Copper Beryllium Alloy |
| Body Plating | Gold Plating (Nickel underplated) |
| Cable Group Connectors | Y3 |
| Cable Group2 | Y11 |
| Cable Retention Force | 155N |
| Cable1 | EZ_86_TP_M17 |
| Cable2 | SUCOFORM_86 |
| Cable3 | MULTIFLEX_86 |
| Centre Contact Material | Copper Beryllium Alloy |
| Centre Contact Plating | Gold Plating (Nickel underplated) |
| Connector Description | Straight cable plug |
| CONNECTOR SERIES | SMA |
| Coupling Nut Material | Bronze |
| Coupling Nut Plating | Gold Plating (Nickel underplated) |
| Dielectric Size | 2mm |
| Gasket Material | VMQ (Silicone rubber) |
| Gender | plug |
| ID | 11_SMA-50-2-15/111_N |
| Impedance | 50 |
| Insulator Material | PFA / PTFE |
| Interface Frequency max. | 18GHz |
| Interface Standards | IEC 60169-15_MIL-STD-348A/310_CECC 22110 |
| Junction | cable |
| 2011/65/EC (RoHS) | compliant |
| Mounting | none |
| Number of Matings | 500 |
| Operating Temperature max. | 165°C |
| Operating Temperature min. | -65°C |
| Outer Contact Material | Copper Beryllium Alloy |
| Outer Contact Plating | Gold Plating (Nickel underplated) |
| Packaging | Bulk 100 pcs |
| PATTERN CLASSES | 11 |
| Weight | 0.0022kg |
| CONNECTOR SHAPE | straight |
| Type Number | 11_SMA-50-2-15/111_NH |
| OBJECT_ID | 7668526 |
