Produktnummer: 85018124
Huber Suhner

Mechanical Thermal Properies Tight bending radii
Impact Standard IEC 60794-1-21 E4
Stripping Tube can be stripped up to 2m in one piece
Tension Test Standard IEC 60794-1-21 E1
Strain Reliefed Armouring Strain relieved with aramide yarn
Wavelength for singlemode at 1310nm/1550nm
Fire Standard Single IEC 60332-1-2
Temperature Standard IEC 60794-1-22 F1
Crush Test Standard IEC 60794-1-21 E3
Fire Standard Bundle IEC 60332-3-25
Installation No need for cleaning the fibers
Comments Stripping size: Outer jacket: AWG 18 (1.00mm) Tube jacket: AWG 26 (0.40mm) Recommended Multi-Wire Stripper: RIPLEY Cutter 821 26-16 AWG (0.40 - 1.3mm) Part No.: 80568
Trademark LSFH
Class 1032
Cable Type Metal free indoor cable
Cable Description FTTH Cable
Outer Jacket Type Outer jacket / PE flame retardant (LSFH)
Outer Jacket Ø 2.3mm
Reinforcement Type Reinforcement / aramide yarn
Number of max. Fibres 4
Tube Type Multi-fiber loose tube, up to 4 fibers
Fire behavior Low smoke, halogen free and self-extinguishing
ID 04-4E9A2/MH(ZN)H-...23
OBJECT_ID 7333596
