02-G50/V(ZN)H-M21-F#D
Mechanical Thermal Properies | High flexibility |
Tension Test Standard | IEC 60794-1-2 E1 |
Strain Reliefed Armouring | Strain relieved with aramide yarn |
Wavelength | for singlemode at 1550nm, for multimode at 1300nm |
Fire Standard Single | IEC 60332-1-2 |
Temperature Standard | IEC 60794-1-2 F1 |
Crush Test Standard | IEC 60794-1-2 E3 |
Fire Standard Bundle | IEC 60332-3-25 |
Installation | Tight bending radii |
Other Properties | Jacket material according to UL 94V-0 |
Class | 1032 |
Application | For direct connector assembly |
Cable Type | Metal free indoor cable |
Cable Description | Riser Cable |
Outer Jacket Type | Outer jacket / PE flame retardant (LSFH) |
Outer Jacket Ø | 2.1mm |
Reinforcement Type | Reinforcement / aramide yarn |
Number of max. Fibres | 2 |
Tube Type | Tight tube |
Fire behavior | Low smoke, halogen free and self-extinguishing |
ID | 02-.../V(ZN)H-...21 |
OBJECT_ID | 8677659 |
