22_SHV-50-0-11/100_NE
Coaxial connector
SHV, 50 Ohm, Straight bulkhead receptacle, female
| H+S | |
|---|---|
| Insulator | PFA / PTFE |
| Centre contact | Copper Beryllium Alloy / Gold Plating (Nickel underplated) |
| Connector type | Straight bulkhead receptacle jack |
| Tab style | others |
| Details | CAS: 7439-92-1 Lead |
| Fastening nut | Brass / Silver Plating |
| Standard | IEC 60498_MIL-STD-348A/314 |
| Washer | Bronze / Silver Plating |
| Mating cycles | 500 |
| Product code | 22_SHV-50-0-11/100_N |
| Gasket | FKM (Fluoro elastomer, FPM) |
| Weight | 0.0212 kg |
| Exemptions | 6c |
| Flange type | round flange / dia. 17.5 |
| Interface frequency | 0.3 GHz |
| Directive | RoHS 2011/65/EU and (EU) 2015/863 |
| Interface type | SHV |
| Gender | jack |
| Rating | Contains one or more SVHC >0,1% , Compliant with exemption |
| Operation temperature | -65 °C ... 165 °C |
| Body | Brass / Silver Plating |
| Impedance | 50 Ω |
| Regulation | REACH 1907/2006 Article 33 SVHC |
| Outer conductor | Brass / Silver Plating |
